| Tecnical data |
| Nominal voltage Applications | 100/100 V |
| Applications / Usage conditions | Use with hand held welding electrodes at 100 V. |
| Conductor | Flexible red copper |
| Sheath type | EM5 (EN 50363-2-2) |
| Sheath colour | Black |
| Operating temperatures | -20° C | +85° C |
| Short circuit temperature | max 200° C (max 5 sec.) |
| Test voltage | 1000 V |
| Cable markings | IEMMEQU H01N2-D (sect) mm² CE |
| Minimum bending radius | For cable up to 12 mm, 4 times the max external diameter in mobile laying and 3 times in fixed laying. For cable over 12 mm, 5 times the max exteranl diameter for mobile laying and 4 times in fixed laying. |
